GDM101PM32D1597-A00
1. GENERAL DESCRIPTION
The display model GDM101PM32D1597-A00 is a ALL O‘ clock TFT-LCD (Thin Film Transistor Liquid Crystal Display) module. This model is Composed of a TFT LCD panel , a driving circuit and a back light, and also has a 10.1 inch diagonally measured active display area with FHD(1200 horizontal by 1920 vertical pixel) resolution in a stripe arrangement.
Display 16.7M colors by 8 bit R.G.B signal input.
General specifications are summarized in the following table：
1.1 General information
2. ABSOLUTE MAXIMUM RATINGS
2.1 Electrical Absolute Rating:
2.2 Environment Absolute Rating
2.2 Environment Absolute Rating
3. OPTICAL CHARACTERISTICS
3.1 Optical specification
3.2 Measuring Condition
A Measuring surrounding:dark room
B Ambient temperature: 25+/-2 ℃
3.3 Measuring Equipment
A FPM520 of Westar Display technologies, INC., which utiliaed Sr-3
for Chromaticity and BM-5A for other optical characteristics.
B Measuring spot size:20-21 mm
